Custom Silicone Rubber Cylinder Bushing

Payment Type:	T/T
Terms of Trade:	FOB,CIF,EXW
Min. Order:	1 Bag/Bags
Delivery Time:	1-7 Days

Packaging:	carton package
Productivity:	100, 000PCS/Week
Transportation:	Ocean,Land,Air
Supply Ability:	100, 000PCS/Week
Port:	Xiamen

Product Description

Rubber Bushing > Custom Silicone Rubber Cylinder Bushing

Silicone Rubber Cylinder Bushing Definition
Silicone Rubber Cylinder Bushing, serving as a vibration isolator, is also known as rubber cylinder bushing, silicone cylinder damper, silicone cylinder washer, etc, which is mostly applied in mechanical moving parts, valve, shaft, medical devices, auto industry

Rubber Bushing Silicone Bushing,Silicone Sleeve Bushing,Silicone Rubber Bushing,Rubber Sleeve Bushing

. And it provides an interface between two parts, damps the energy transmitted, absorbs shock & vibration and reduce noise.

Silicone Rubber Cylinder Bushing Function
Silicone rubber cylinder bushing can be replaced very conveniently if it worn out. Otherwise, you have to replace the whole part once abrasion. Now, people tend to replace the bushing (while designing, the hardness of bushing can be reduced to be a bearing grinding of friction pair) due to its convenient processing, low replacement cost and easy replacement, of course, also including other secondary functions, like guiding function, and etc.

Silicone Silicone rubber cylinder bushing occupies a prominent place in vehicle suspension systems, where a bushing made of rubber (or, more often, synthetic rubber or polyurethane) separates the faces of two metal objects meanwhile allowing a certain amount of movement. This movement allows the suspension parts to move freely. For example, when the vehicle travels over a large bump, the transmission of noise and vibrations from the chassis can be minimized. Therefore, a silicone rubber cylinder bushing may also be described as a flexible mounting or antivibration mounting.

Silicone Rubber Cylinder Bushing Feature
Various hardness for your choice.
Oil resistance.
Good anti-aging performance.
Good gas tightness
Good abrasion resistance .
Easy to bond to other material.
Excellent oxygen and ozone resistance.
Non-flammable,self-extinguish.
High heat resistance.

Silicone Rubber Cylinder Bushing Specification

Material	EPDM, NR, Silicon, FKM,IIR,NBR,SBR,Sponge Rubber, or Custom Compound
Color	Black,white,red,green,transparent or any color according to Pantone colors
Size	As per customer's requirements
Hardness	Shore A
Service	OEM or ODM
Production basis	Samples or drawings
Technology	Hot pressing molding ,injection molding or extrusion
Working temperature	-60~350ºC
Tolerance	±0.05mm
Density	1.0-2.0g/cm³
MOQ	1 pc
Certification	ROHS,FDA,ISO9001:2000
Conductivity	Conductive or insulative
Working life	1-30 years
Samples	1-2 pcs of free samples are available
Application	Automotive,Mechanical equipment,Construction,Home appliance,Aviation, Office facilities,

Bushing categories based on materials performance

NBR Bushing	excellent resistant to oil,widely used in industrial area
EPDM Bushing	excellent resistance to weather and ozone,good resistance to heat,low temperature and chemical
NR Bushing	high elasticity,good chemical strength
CR Bushing	generally good resistance to ozone,aging,and chemical,good mechanical properties over a wide temperature range
SBR Bushing	shock resistance,performance well in adhesion and sealing
Silicone Bushing	widest operating temperature range,performance stably in high and low temperature,widely use in food sealing area
VT/FKM Bushing	excellent resistance to high temperature and a broad range of chemical,permeability and compression set are excellent
HNBR Bushing	thermal stability and oxidation resistance
IIR Bushing	low permeability rate and good electrical properties
FVMQ Bushing	widest operating temperature range,performance stably in high and low temperature,good resistance to oil and fuel
ACM Bushing	good resistance to mineral to oil,oxygen and ozone

Silicone Bushing's Manufacturing Process
Silicone bushing is manufactured by compression molding in our Automatic Hydraulic Compression Molding Presses.
Along with our in-house tool room, and highly experienced manufacturing team, our various Molding machines enable us to deliver:

Uniform Vulcanization / Curing of the Material: All parameters (like pressure, temperature and vulcanization time) are automatically controlled.
Excellent Dimensional Accuracy: We offer high dimensional accuracy in the silicone rubber cylinder bushing.

A wide range of designs and sizes: We offer rubber bushes in a great variety of designs/sizes.
